| Part Number | LTA320AN12 |
| Mark | Samsung |
| Gréisst | 31.5 |
| Applikatioun | LCTV |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 320 |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTA320AN12 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 31.5 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | PVA, Normally Black, Transmissive |
| aktiv Beräich | 697.685×392.256 mm |
| skizzéieren | 734.4×430.3 mm |
| Uewerfläch | Antiglare, Hard coating |
| Hellegkeet | 320 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 20 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| LTA320AP05 | Samsung | 31.5 | 1366×768 |
| LTA320AP13 | Samsung | 31.5 | 1366×768 |
| LTA320AP21 | Samsung | 31.5 | 1366×768 |
| LTA320AP29-W | Samsung | 31.5 | 1366×768 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA320HJ02 | Samsung | 31.5 | 1920×1080 |
| LTA320HN04-W | Samsung | 31.5 | 1920×1080 |
| LTA320W2-L03 | Samsung | 31.5 | 1366×768 |
| LTA320WT-L08 | Samsung | 31.5 | 1366×768 |
| LTA320WT-LF1 | Samsung | 31.5 | 1366×768 |
| HT260WXC-100 | BOE | 26.0 | 1366×768 |
| HV320WHB-N06 | BOE | 31.5 | 1366×768 |
| LC320EXJ-SEK1 | LG Display | 31.5 | 1366×768 |
| LC320WXE-SBV2 | LG Display | 31.5 | 1366×768 |
| LC420WUE-SCV1 | LG Display | 42 | 1920×1080 |
| LC470EUN-SEM1 | LG Display | 47 | 1920×1080 |
| LTY320HN03 | Samsung | 31.5 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| ST3151A05-5 | CSOT | 31.5 | 1366×768 |
| T260XW03 V3 | AUO | 26.0 | 1366×768 |
