Samsung LTA320AP12 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LTA320AP12

LTA320AP12
LTA320AP12
LTA320AP12 thumb LTA320AP12 thumb
Mark
Samsung
Gréisst
31.5
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
450
CR
4000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
19674
Spezifikatioune

Part Number LTA320AP12
MarkSamsung
Gréisst31.5
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet450
CR4000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkSAMSUNG
Panel ModellLTA320AP12
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst31.5 inch
Resolutioun1366×768(RGB) , WXGA
Display ModusAPVA, Normally Black, Transmissive
aktiv Beräich697.685×392.256 mm
skizzéieren760×450 mm
UewerflächAntiglare (Haze 7%), Hard coating (3H)
Hellegkeet450 cd/m² (Typ.)
Kontrast Verhältnis4000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit8 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 pcsCCFLEmbedded (Inverter)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LTA320AN01-C Samsung 31.5 1366×768
LTA320AN12 Samsung 31.5 1366×768
LTA320AP13 Samsung 31.5 1366×768
LTA320AP16 Samsung 31.5 1366×768
LTA320AP33 Samsung 31.5 1366×768
LTA320HA04 Samsung 31.5 1920×1080
LTA320HJ03 Samsung 31.5 1920×1080
LTA320HM03 Samsung 31.5 1920×1080
LTA320HN02-W Samsung 31.5 1920×1080
LTA320HN03-W Samsung 31.5 1920×1080
