| Part Number | LSC480HN10 |
| Mark | SAMSUNG |
| Gréisst | 48 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 4000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | LVDS |
| Mark | SAMSUNG |
| Modell | LSC480HN10 |
| diagonal Gréisst | 48 inch |
| Typ | a-Si TFT-LCD, CELL |
| Pixel Format | 1920×1080(RGB) [FHD] 46PPI |
| Configuratioun | RGB Horizontal Stripe |
| aktiv Beräich | 1054.08(H)×592.92(V) mm |
| kontur dim. | 1068.08(H)×608.92(V) ×1.4(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare, Hard coating (2H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 4000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | SVA, Normally Black, Transmissive |
| Plackedicke | 0.50+0.50 mm |
| Iwwerdroung | 6.6% (Typ.)(with Polarizer) |
| Ënnerstëtzung Faarf | 1.07B 68% NTSC |
| Liichtquell | No B/L |
| Gewiicht | 1.90Kgs (Typ.) |
| entworf fir | TV Sets |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| d-ic detail | COF Built-in 2 source chips |
| Interface Typ | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
