| Part Number | ST4761B01-5 |
| Mark | CSOT |
| Gréisst | 48 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Panel Mark | CSOT |
| Panel Modell | ST4761B01-5 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 48 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | HVA, Normally Black, Transmissive |
| aktiv Beräich | 1054.08×592.92 mm |
| skizzéieren | 1068.75×607.61 mm |
| Uewerfläch | Antiglare (Haze 2%), Hard coating (2H) |
| Glas Déift | 0.50+0.50 mm |
| transmissivitéit | 5.7% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 9.5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Signal Interface | LVDS (2 ch, 8-bit) |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| HV480FH2-600 | BOE | 48 | 1920×1080 |
| LSC480FJ01 | Samsung | 48 | 3840×2160 |
| ST4761B01-5 | CSOT | 48 | 1920×1080 |
| ST4761B02-1 | CSOT | 48 | 1920×1080 |
| LC320WXE-SBV2 | LG Display | 31.5 | 1366×768 |
| LC550DUS-SCM3 | LG Display | 55 | 1920×1080 |
| LTA460HT-LH3 | Samsung | 46 | 1920×1080 |
| LTA550HW04 | Samsung | 55 | 1920×1080 |
| T315XW06 V6 | AUO | 31.5 | 1366×768 |
| T500HVD01.0 | AUO | 50 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V260H1-P03 | Innolux | 26.0 | 1920×1080 |
| V315H3-LE1 | Innolux | 31.5 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
