| Part Number | LS050T1SX18 |
| Mark | Sharp |
| Gréisst | 5.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 1080×1920 |
| Zesummesetzung | CG-Silicon, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S2P |
| Interface | MIPI |
| Panel Mark | Sharp |
| Panel Modell | LS050T1SX18 |
| Panel Gréisst | 5.0" |
| Panel Typ | CG-Silicon, LCM |
| Resolutioun | 1080(RGB)×1920, FHD, 445PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 61.641(W)×109.584(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 63.64(W)×116.224(H) ×1.16(D) mm |
| Uewerfläch | - |
| Hellegkeet | 480 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| Display Modus | New Mode2, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| weisen Faarwen | 16.7M 95% NTSC |
| Lampe Typ | 6S2P WLED , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | PCAP |
| Panel Gewiicht | 14.0g (Typ.) |
| Applikatioun | Mobile Phone |
| Signal Interface | MIPI (4 data lanes) , 40 pins Connector |
| Input Volt | 1.8/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
