| Part Number | LQ156D1JX36x |
| Mark | Sharp |
| Gréisst | 15.6 |
| Applikatioun | Laptop |
| Opléisung | 3840×2160 |
| Zesummesetzung | Oxide TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | Sharp |
| diagonal Gréisst | 15.6 inch |
| Pixel Format | 3840(RGB)×2160 [UHD] 282PPI |
| aktiv Beräich | 345.6(H)×194.4(V) mm |
| bezel Beräich | - |
| luminance | 300 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 100% sRGB |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Frame Taux | 60Hz |
| Interface Typ | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| Modell | LQ156D1JX36x (SHP1480) |
| Typ | Oxide TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 351.9(H)×217.2(V) ×2.75(D) mm |
| Behandlung | Glare (Haze 0%), Hard coating (3H) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Äntwert Zäit | 33 (Typ.)(Tr+Td) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Liichtquell | WLED , 15K hours , With LED Driver |
| entworf fir | Laptop |
| Touch Panel | Without |
