| Part Number | LQ156D1JW04 |
| Mark | SHARP |
| Gréisst | 15.6 |
| Applikatioun | NBPC |
| Opléisung | 3840×2160 |
| Zesummesetzung | LCM |
| Hellegkeet | 330 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | SHARP |
| Panel Modell | LQ156D1JW04 |
| Panel Typ | IGZO TFT-LCD , LCM |
| Panel Gréisst | 15.6 inch |
| Resolutioun | 3840(RGB)×2160 , UHD |
| Display Modus | New Mode2, Normally Black, Transmissive |
| aktiv Beräich | 345.6×194.4 mm |
| skizzéieren | 367.98×218.31×3.14 mm |
| Form Stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 330 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
