| Part Number | LQ150X1LW94 |
| Mark | SHARP |
| Gréisst | 15.0 |
| Applikatioun | GM |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1500:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LQ150X1LW94 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | ASV, Normally Black, Transmissive |
| aktiv Beräich | 304.128×228.096 mm |
| skizzéieren | 326.5×253.5×10.1 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193170% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | GM |
