| Part Number | TX48D80VM1CAA |
| Mark | KOE |
| Gréisst | 19.0 |
| Applikatioun | GM |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 200:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | HITACHI |
| Panel Modell | TX48D80VM1CAA |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 19.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 385.536×289.152 mm |
| skizzéieren | 410×324×17.5 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 200:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 30/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/45/60 (Typ.)(CR≥5)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | GM |
| FLC48SXC8V-11AA | Fujitsu | 19.0 | 1280×1024 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| LQ104V1DG83 | SHARP | 10.4 | 640×480 |
| LQ121S1LG72 | SHARP | 12.1 | 800×600 |
| LQ121S1LG74A | SHARP | 12.1 | 800×600 |
| LQ121S1LG75 | SHARP | 12.1 | 800×600 |
| LQ196A1LZ03 | SHARP | 19.6 | 1600×1200 |
| LT100AA40000 | TOSHIBA | 10.0 | 800×600 |
| LTA159B870F | TOSHIBA | 15.9 | 1280×645 |
| LTA197B0H0F | TOSHIBA | 19.7 | 1280×960 |
| TX26D89VM2BAA | KOE | 10.2 | 800×256 |
