| Part Number | LQ150U1LW22 |
| Mark | SHARP |
| Gréisst | 15.0 |
| Applikatioun | NBPC |
| Opléisung | 1600×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 180 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LQ150U1LW22 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1600(RGB)×1200 , UXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 304×228 mm |
| skizzéieren | 317.3×242×7 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Antiglare, Hard coating (2H), Reflection 1.7% (Max.) |
| Hellegkeet | 180 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 9/16 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
