| Part Number | LQ12S41 |
| Mark | SHARP |
| Gréisst | 12.1 |
| Applikatioun | IA |
| Opléisung | 800×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 270 |
| CR | 150:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ12S41 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.1 inch |
| Resolutioun | 800(RGB)×600 , SVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 246×184.5 mm |
| skizzéieren | 290×225×13.7 mm |
| Uewerfläch | Antiglare (Haze 28%), Hard coating (3H) |
| Hellegkeet | 270 cd/m² (Typ.) |
| Kontrast Verhältnis | 150:1 (Min.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 20/40 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/55/55 (Min.)(CR≥5)(L/R/U/D) |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 41 pins |
| Input Volt | 3.3V (Typ.)(VCC) |
| Applikatioun | IA |
