SHARP LQ121S1LG55 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LQ121S1LG55

LQ121S1LG55
LQ121S1LG55
LQ121S1LG55
LQ121S1LG55 thumb LQ121S1LG55 thumb LQ121S1LG55 thumb
Mark
SHARP
Gréisst
12.1
Applikatioun
GM
Opléisung
800×600
Zesummesetzung
LCM
Hellegkeet
330
CR
450:1
Faarwen
16.2M
Backlight
CCFL
Interface
LVDS
In Stock
7682
Spezifikatioune

Part Number LQ121S1LG55
MarkSHARP
Gréisst12.1
ApplikatiounGM
Opléisung800×600
ZesummesetzungLCM
Hellegkeet330
CR450:1
Faarwen16.2M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkSHARP
Panel ModellLQ121S1LG55 1 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst12.1 inch
Resolutioun800(RGB)×600 , SVGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich246×184.5 mm
skizzéieren276×209×11 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet330 cd/m² (Typ.)
Kontrast Verhältnis450:1 (Typ.)
weisen Faarwen16.2M (8-bit), CIE193172%
Äntwert Zäit35 (Typ.)(Tr+Td); 10 (Typ.)(G to G)
Vue Wénkel70/70/50/60 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ2 pcsCCFLWithout Driver
Signal InterfaceLVDS (1 ch, 8-bit), 20 pins
Input Volt3.3V (Typ.)
ApplikatiounGM
Famill Modell
LQ121S1DC71 SHARP 12.1 800×600
LQ121S1DG21 SHARP 12.1 800×600
LQ121S1DG21A SHARP 12.1 800×600
LQ121S1DG42 SHARP 12.1 800×600
LQ121S1DG61 SHARP 12.1 800×600
LQ121S1LG41 SHARP 12.1 800×600
LQ121S1LG45 SHARP 12.1 800×600
LQ121S1LG61 SHARP 12.1 800×600
LQ121S1LG75 SHARP 12.1 800×600
LQ121X1LH83 SHARP 12.1 1024×768
