| Part Number | LQ106K1LA05 |
| Mark | SHARP |
| Gréisst | 10.6 |
| Applikatioun | NBPC |
| Opléisung | 1280×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 350:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LQ106K1LA05 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.6 inch |
| Resolutioun | 1280(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 230.4×138.24 mm |
| skizzéieren | 257.8×152×5 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H), Antireflection |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 350:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 9S5PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
