LP141WX1-TL01

LP141WX1-TL01
LP141WX1-TL01 thumb
Mark
LG Display
Gréisst
14.1
Applikatioun
NBPC
Opléisung
1280×800
Zesummesetzung
LCM
Hellegkeet
185
CR
350:1
Faarwen
262K
Backlight
CCFL
Interface
LVDS
In Stock
17480
Spezifikatioune

Part Number LP141WX1-TL01
MarkLG Display
Gréisst14.1
ApplikatiounNBPC
Opléisung1280×800
ZesummesetzungLCM
Hellegkeet185
CR350:1
Faarwen262K
GéigeliichtCCFL
InterfaceLVDS
Panel MarkLG.Philips LCD
Panel ModellLP141WX1-TL01 9 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst14.1 inch
Resolutioun1280(RGB)×800 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich303.74×189.84 mm
skizzéieren319.5×217.4×5.5 mm
Form StilWedge (PCBA Bent, Depth ≥5.2mm)
UewerflächAntiglare
Hellegkeet185 cd/m² (Typ.)
Kontrast Verhältnis350:1 (Min.)
weisen Faarwen262K (6-bit), CIE193145%
Äntwert Zäit6/19 (Typ.)(Tr/Td)
Vue Wénkel40/40/15/30 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ1 pcsCCFLWithout Driver
Signal InterfaceLVDS (1 ch, 6-bit), 30 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
