| Part Number | LP141WX5-TLN1 |
| Mark | LG Display |
| Gréisst | 14.1 |
| Applikatioun | NBPC |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 220 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LP141WX5-TLN1 2 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.1 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 303.74×189.84 mm |
| skizzéieren | 319.5×205.5×5.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S6PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LP141WP1-TLA2 | LG Display | 14.1 | 1440×900 |
| LP141WP2-TLA2 | LG Display | 14.1 | 1440×900 |
| LP141WX1-TL02 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLA4 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLB1 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLN1 | LG Display | 14.1 | 1280×800 |
| LP141WX3-TLR1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP3 | LG Display | 14.1 | 1280×800 |
| B156XTN02.2 | AUO | 15.6 | 1366×768 |
| LP140QH1-SPA2 | LG Display | 14.0 | 2560×1440 |
| LP140WH4-TLC1 | LG Display | 14.0 | 1366×768 |
| LTN141AT03-301 | Samsung | 14.1 | 1280×800 |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN154U2-L04-0 | Samsung | 15.4 | 1920×1200 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT06-001 | Samsung | 15.6 | 1366×768 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
