| Part Number | LPM013M461B |
| Mark | JDI |
| Gréisst | 1.29 |
| Applikatioun | Wearable |
| Opléisung | 260×260 |
| Zesummesetzung | LCM , LTPS TFT-LCD |
| Hellegkeet | |
| CR | 20:1 |
| Faarwen | 64 |
| Géigeliicht | No B/L |
| Interface | |
| Fabrikant beschwéiert | JDI |
| Modell Numm | LPM013M461B |
| Écran Gréisst | 1.29 inch |
| Écran Typ | LCM , LTPS TFT-LCD |
| Pixel Zuel | 260(RGB)×260 201PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 32.76 × 32.76 (H×V) |
| Kontur (mm) | 35.56 × 36.26 × 1.01 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Hard coating (2H) |
| luminance | - |
| Kontrast Verhältnis | 20:1 (Typ.) (RF) |
| Vue Wénkel | 60/65/65/60 (Typ.)(CR≥2) |
| Äntwert | 3/6 (Typ.)(Tr/Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | ECB, Normally Black, Reflective |
| Faarfdéift | 64 23% NTSC |
| mass | 1.90g (Typ.) |
| benotzt fir | Wearable |
| Erfrëschungsrate | 30Hz |
| touchscreen | Without |
| Spannungsversuergung | 3.2/4.5V (Typ.)(VDD1/VDD2) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| LPM010R030B | JDI | 0.99 | 180×180 |
| LPM012A154A | JDI | 1.2 | 218×218 |
| LPM013M091A | JDI | 1.34 | 320×300 |
