| Part Number | LP171WU1-TLA1 |
| Mark | LG Display |
| Gréisst | 17.1 |
| Applikatioun | NBPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 260 |
| CR | 700:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LP171WU1-TLA1 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.1 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 367.2×229.5 mm |
| skizzéieren | 382.2×267.2×6.6 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H) |
| Hellegkeet | 260 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LP171WE3-TLA3 | LG Display | 17.1 | 1680×1050 |
| LP171WE3-TLA5 | LG Display | 17.1 | 1680×1050 |
| LP171WP4-TLB3 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLP1 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLQ1 | LG Display | 17.1 | 1440×900 |
| LP171WP7-TLB1 | LG Display | 17.1 | 1440×900 |
| LP171WP9-TLB3 | LG Display | 17.1 | 1440×900 |
| LP171WU5-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-A4K7 | LG Display | 17.1 | 1440×900 |
| LP171WX2-TLB1 | LG Display | 17.1 | 1440×900 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| LP133WP1-TJAA | LG Display | 13.3 | 1440×900 |
| LP140WH2-TLF3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP150X08-TLAD | LG Display | 15.0 | 1024×768 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LQ164M1LG4B | SHARP | 16.4 | 1920×1080 |
| LTN156AT35-H01 | Samsung | 15.6 | 1366×768 |
| M140NWR4 R2 | IVO | 14.0 | 1366×768 |
