LP156WH3-TLA2

LP156WH3-TLA2
LP156WH3-TLA2
LP156WH3-TLA2 thumb LP156WH3-TLA2 thumb
Mark
LG Display
Gréisst
15.6
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
200
CR
500:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
11332
Spezifikatioune

Part Number LP156WH3-TLA2
MarkLG Display
Gréisst15.6
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet200
CR500:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLP156WH3-TLA2 21 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst15.6 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich344.232×193.536 mm
skizzéieren359.5×223.4×3.8 mm
Form StilFlat (PCBA Flat, Depth 3.4~4.0mm)
UewerflächGlare (Haze 0%), Hard coating (3H)
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis500:1 (Typ.)
weisen Faarwen262K (6-bit), CIE193145%
Äntwert Zäit16 (Typ.)(Tr+Td)
Vue Wénkel40/40/10/30 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ7S6PWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 6-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
Famill Modell
LP156WD1-TLA1 LG Display 15.6 1600×900
LP156WD1-TPB1 LG Display 15.6 1600×900
LP156WH1-TLA3 LG Display 15.6 1366×768
LP156WH2-TLB1 LG Display 15.6 1366×768
LP156WH2-TLF1 LG Display 15.6 1366×768
LP156WH2-TLQB LG Display 15.6 1366×768
LP156WH4-TPP1 LG Display 15.6 1366×768
LP156WHA-SLA2 LG Display 15.6 1366×768
LP156WHB-TLA1 LG Display 15.6 1366×768
LP156WHU-TPB1 LG Display 15.6 1366×768
