| Part Number | LP154WU1-TLC1 |
| Mark | LG Display |
| Gréisst | 15.4 |
| Applikatioun | NBPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 210 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LP154WU1-TLC1 3 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.4 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 331.2×207 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Antiglare |
| Hellegkeet | 210 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Min.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 60/60/40/50 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP154W01-TLAE | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL10 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| LP154WX4-TLB4 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA2 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP2 | LG Display | 15.4 | 1280×800 |
| HB133WX1-402 | BOE | 13.3 | 1366×768 |
| HSD121PHW2-A00 | HannStar | 12.1 | 1366×768 |
| LP133WX1-TLB1 | LG Display | 13.3 | 1280×800 |
| LP150X09-A5K1 | LG Display | 15.0 | 1024×768 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LP171WU3-TLB1 | LG Display | 17.1 | 1920×1200 |
| LTM15C162 | TOSHIBA | 15.0 | 1600×1200 |
| LTN156HT01-101 | Samsung | 15.6 | 1920×1080 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
