LG Display LP140WH6-TJA1 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LP140WH6-TJA1

LP140WH6-TJA1
LP140WH6-TJA1 thumb
Mark
LG Display
Gréisst
14.0
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
CELL
Hellegkeet
0
CR
500:1
Faarwen
262K
Backlight
No B/L
Interface
LVDS
In Stock
6820
Spezifikatioune

Part Number LP140WH6-TJA1
MarkLG Display
Gréisst14.0
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungCELL
Hellegkeet0
CR500:1
Faarwen262K
GéigeliichtNo B/L
InterfaceLVDS
Panel MarkLG Display
Panel ModellLP140WH6-TJA1
Panel Typ a-Si TFT-LCD , CELL
Panel Gréisst14.0 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich309.399×173.952 mm
skizzéieren322.3×198.68 mm
UewerflächGlare (Haze 0%), Hard coating (3H)
Glas Déift0.50+0.50 mm
transmissivitéit6.1% (Typ.)(with Polarizer)
Kontrast Verhältnis500:1 (Typ.)
weisen Faarwen262K (6-bit), CIE193145%
Äntwert Zäit16 (Typ.)(Tr+Td)
Vue Wénkel45/45/15/35 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Signal InterfaceLVDS (1 ch, 6-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
