| Part Number | LP121WX3-TLA1 |
| Mark | LG Display |
| Gréisst | 12.1 |
| Applikatioun | NBPC |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LP121WX3-TLA1 5 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.1 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 261.12×163.2 mm |
| skizzéieren | 275.8×178.1×5.5 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 16 (Typ..)(Tr+Td) |
| Vue Wénkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| B121EW03 V6 | AUO | 12.1 | 1280×800 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| LB121S03-TL02 | LG Display | 12.1 | 800×600 |
| LLB121ST01 | Samsung | 12.1 | 800×600 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LP121WX3-TLB1 | LG Display | 12.1 | 1280×800 |
| LP121WX3-TLC1 | LG Display | 12.1 | 1280×800 |
| LP121WX3-TPB1 | LG Display | 12.1 | 1280×800 |
| LP121WX4-TLA1 | LG Display | 12.1 | 1280×800 |
| LTD121C33U | TOSHIBA | 12.1 | 800×600 |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| B154SW01 V1 | AUO | 15.4 | 1680×1050 |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP156WF4-SPU1 | LG Display | 15.6 | 1920×1080 |
| LP156WH4-TLA1 | LG Display | 15.6 | 1366×768 |
| LP171WU8-SLB1 | LG Display | 17.1 | 1920×1200 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| N121I3-L01 | Innolux | 12.1 | 1280×800 |
| N140BGE-L11 | Innolux | 14.0 | 1366×768 |
