| Part Number | LP097QX2-SPAV |
| Mark | LG Display |
| Gréisst | 9.7 |
| Applikatioun | PAD |
| Opléisung | 1536×2048 |
| Zesummesetzung | LCM |
| Hellegkeet | 440 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | LG Display |
| Panel Modell | LP097QX2-SPAV |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 9.7 inch |
| Resolutioun | 1536(RGB)×2048 , QXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 147.456×196.608 mm |
| skizzéieren | 160.3×208.93 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H), Antireflection |
| Hellegkeet | 440 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 42 pins |
| Input Volt | 3.7V (Typ.) |
| Applikatioun | PAD |
