| Part Number | LMS340KC01-001 |
| Mark | Samsung |
| Gréisst | 3.4 |
| Applikatioun | MPH |
| Opléisung | 720×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SAMSUNG |
| Panel Modell | LMS340KC01-001 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 3.4 inch |
| Resolutioun | 720(RGB)×480 |
| Display Modus | PVA, Normally Black, Transmissive |
| aktiv Beräich | 71.82×47.88 mm |
| skizzéieren | 82.22×53.88×21 mm |
| Uewerfläch | Hard coating (2H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| Input Volt | 1.8/2.8V (Typ.)(VDD1/VDD2) |
| Applikatioun | MPH |
