| Part Number | LM230WF9-SSA1 |
| Mark | LG Display |
| Gréisst | 23.0 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | LG Display |
| Modell | LM230WF9-SSA1 |
| diagonal Gréisst | 23.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 95PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 509.184(H)×286.416(V) mm |
| kontur dim. | 516.984(H)×302.708(V) ×14.2(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED [14S4P] , 30K hours , W/O Driver |
| Gewiicht | 1.79/1.88Kgs (Typ./Max.) |
| entworf fir | Desktop Monitor |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
