| Part Number | LM201WE3-TLJ3 |
| Mark | LG Display |
| Gréisst | 20.1 |
| Applikatioun | DMPC |
| Opléisung | 1680×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LM201WE3-TLJ3 0 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 20.1 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 433.44×270.9 mm |
| skizzéieren | 459.4×296.4 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H), Reflection 2.5% (Typ.) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 1.1/3.9 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| LM170E03-TLJ1 | LG Display | 17.0 | 1280×1024 |
| LM171WX3-TLC2 | LG Display | 17.1 | 1440×900 |
| LTM230HT01 | Samsung | 23.0 | 1920×1080 |
| M201EW02 V9 | AUO | 20.1 | 1680×1050 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| MT170EN01 V.9 | Innolux | 17.0 | 1280×1024 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
