| Part Number | LM170E03-TLJ1 |
| Mark | LG Display |
| Gréisst | 17.0 |
| Applikatioun | DMPC |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LM170E03-TLJ1 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.0 inch |
| Resolutioun | 1280(RGB)×1024 , SXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 337.92×270.336 mm |
| skizzéieren | 358.5×296.5×14 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 1.2/3.8 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LM170E01-A4 | LG Display | 17.0 | 1280×1024 |
| LM170E01-A6 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ2 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ5 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLL2 | LG Display | 17.0 | 1280×1024 |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| HM200WD1-100 | BOE | 20.0 | 1600×900 |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| M170EN01 V9 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| M240HW02 V6 | AUO | 24.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
