| Part Number | LM156LFGL01 |
| Mark | PANDA |
| Gréisst | 15.6 |
| Applikatioun | Laptop Gaming |
| Opléisung | 1920×1080 |
| Zesummesetzung | Oxide TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | 9S5P |
| Interface | eDP |
| Panel Mark | PANDA |
| Panel Modell | LM156LFGL01 (NCP0036) |
| Panel Gréisst | 15.6" |
| Panel Typ | Oxide TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×1080, FHD, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 344.16(W)×193.59(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 350.66(W)×216.245(H) ×3.2(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | FFS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Tf) |
| weisen Faarwen | 262K 45% NTSC |
| Lampe Typ | 9S5P WLED , 15K hours , With LED Driver |
| Frequenz | 120Hz |
| Touchscreens | Without |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Applikatioun | Laptop Gaming |
| Signal Interface | eDP (4 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
