| Part Number | LH470WX6-SD01 |
| Mark | LG Display |
| Gréisst | 4.7 |
| Applikatioun | MPH |
| Opléisung | 750×1334 |
| Zesummesetzung | Assembly |
| Hellegkeet | 550 |
| CR | 1600:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH470WX6-SD01 |
| Panel Typ | LTPS TFT-LCD , Assembly |
| Panel Gréisst | 4.7 inch |
| Resolutioun | 750(RGB)×1334 , WXGA |
| aktiv Beräich | 58.5×104.052 mm |
| skizzéieren | 61.61×135.77×2.22 mm |
| Uewerfläch | |
| Hellegkeet | 550 cd/m² (Typ.) |
| Kontrast Verhältnis | 1600:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (3 data lanes), 30 pins |
| Input Volt | 1.8/1.8/5.7/-5.7V (Typ.)(DVDD/DPHYVDD/AVDDH/AVDDN) |
| Applikatioun | MPH |
