| Part Number | LC470EUF-PEF1 |
| Mark | LG Display |
| Gréisst | 47 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 1600:1 |
| Faarwen | 16.7M/1.06B |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LC470EUF-PEF1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 47 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | S-IPS, Normally Black, Transmissive |
| aktiv Beräich | 1039.68×584.82 mm |
| skizzéieren | 1059.5×616.2 mm |
| Uewerfläch | Antiglare (Haze 1%), Hard coating (2H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1600:1 (Typ.) |
| weisen Faarwen | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| Äntwert Zäit | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (4 ch, 8/10-bit), 92 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
