| Part Number | LAM170M023A |
| Mark | JDI |
| Gréisst | 17.0 |
| Applikatioun | MD |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 240 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | JDI |
| Panel Modell | LAM170M023A |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.0 inch |
| Resolutioun | 1280(RGB)×1024 , SXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 337.92×270.336 mm |
| skizzéieren | 368×306×20.4 mm |
| Uewerfläch | Antiglare, Hard coating (2H) |
| Hellegkeet | 240 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193174% |
| Äntwert Zäit | 10/12 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3 stringsWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | MD |
