| Part Number | HV208QX1-100 |
| Mark | HYDIS |
| Gréisst | 20.8 |
| Applikatioun | MD |
| Opléisung | 2048×1536 |
| Zesummesetzung | LCM |
| Hellegkeet | 800 |
| CR | 700:1 |
| Faarwen | Grayscale |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | BOE HYDIS |
| Panel Modell | HV208QX1-100 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 20.8 inch |
| Resolutioun | 2048(LCR)×1536 , QXGA |
| Display Modus | AFFS, Normally Black, Transmissive |
| aktiv Beräich | 423.9×318 mm |
| skizzéieren | 457×350 mm |
| Uewerfläch | Antiglare (Haze 13%), Hard coating (3H) |
| Hellegkeet | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | Grayscale (8-bit) |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 12 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (4 ch, 8-bit), 70 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | MD |
