| Part Number | LA123WF4-SR08 |
| Mark | LG Display |
| Gréisst | 12.3 |
| Applikatioun | Automotive Display |
| Opléisung | 1920×720 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S6P WLED , 10K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | LG Display |
| Modell Numm | LA123WF4-SR08 |
| Écran Gréisst | 12.3 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×720 167PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 292.032 × 109.512 (H×V) |
| Kontur (mm) | 310 × 128 × 10.75 (H×V×D) |
| Bezel Beräich (mm) | 296.03 × 113.5 (H×V) |
| Behandlung | Hard coating |
| luminance | 600 cd/m² (Min.) |
| Kontrast Verhältnis | 800 : 1 (Min.) (TM) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Äntwert | 30 (Max.)(G to G); 30 (Typ.)(MPRT) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 77% NTSC |
| mass | - |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
