| Part Number | LA102WH2-SL01 |
| Mark | LG Display |
| Gréisst | 10.2 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 10S4P WLED , 10K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | LG Display |
| Modell Numm | LA102WH2-SL01 |
| Écran Gréisst | 10.2 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1280(RGB)×720 (WXGA) 143PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 225.792 × 127.008 (H×V) |
| Kontur (mm) | 238.62 × 141.5 (H×V×D) |
| Bezel Beräich (mm) | 225.75 × 126.874 (H×V) |
| Behandlung | Hard coating (3H) |
| luminance | 725 cd/m² (Min.) |
| Kontrast Verhältnis | 800 : 1 (Min.) (TM) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Äntwert | 30 (Max.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| Faarfdéift | 16.7M |
| mass | 303/313g (Typ./Max.) |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (1 ch, 8-bit) , FPC 64 pins |
| Spannungsversuergung | 1.8/3.3/12.5/18.5/-7.5V (Typ.)(DVDD2/DVDD1/AVDD/VHG/VHL) |
| max. Bewäertungen | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.16G (31.0 m/s²) |
