| Part Number | LA070WV7-SL02 |
| Mark | LG Display |
| Gréisst | 7.0 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1100:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S3P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | LG Display |
| Modell Numm | LA070WV7-SL02 |
| Écran Gréisst | 7.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 133PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 152.4 × 91.44 (H×V) |
| Kontur (mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| Bezel Beräich (mm) | 158.4 × 94.2 (H×V) |
| Behandlung | Antiglare (Haze 25%) |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 1100 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 16/14 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 65% NTSC |
| mass | 162/167g (Typ./Max.) |
| benotzt fir | Outdoor High Brightness Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (1 ch, 8-bit) , FPC 50 pins |
| Spannungsversuergung | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. Bewäertungen | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
