| Part Number | LA058WQ1-SD01 |
| Mark | LG Display |
| Gréisst | 5.8 |
| Applikatioun | CNS |
| Opléisung | 400×240 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | LG Display |
| Panel Modell | LA058WQ1-SD01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.8 inch |
| Resolutioun | 400(RGB)×240 , WQVGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 126.36×75.84 mm |
| skizzéieren | 152×97 mm |
| Uewerfläch | Antiglare, Antireflection |
| Hellegkeet | |
| Kontrast Verhältnis | |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | WLED |
| Signal Interface | Parallel RGB (1 ch, 6-bit) |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
