| Part Number | JJ070IA-18L |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | Automotive Display |
| Opléisung | 800×480 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S2P WLED , 20K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | Innolux |
| Écran Gréisst | 7.0 inch |
| Pixel Zuel | 800(RGB)×480 (WVGA) 133PPI |
| aktiv Beräich (mm) | 152.4 × 91.44 (H×V) |
| Bezel Beräich (mm) | 155.4 × 94.44 (H×V) |
| luminance | 750 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 195±9g |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 8-bit) , 50 pins FPC |
| Spannungsversuergung | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| max. Bewäertungen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Modell Numm | JJ070IA-18L |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 162.8 × 104.84 (H×V×D) |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 15/10 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| benotzt fir | Automotive Display |
| touchscreen | Without |
