| Part Number | JJ068IA-07B |
| Mark | Innolux |
| Gréisst | 6.8 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1280×720 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S3P WLED , 20K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | Innolux |
| Modell Numm | JJ068IA-07B |
| Écran Gréisst | 6.8 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1280(RGB)×720 (WXGA) 217PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 152.064 × 79.603 (H×V) |
| Kontur (mm) | 167 × 93 × 9.75 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare |
| luminance | 750 cd/m² (Typ.) |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 15/10 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AAS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 185g (Typ.) |
| benotzt fir | Outdoor High Brightness Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
