| Part Number | HT14P12-100 |
| Mark | HYDIS |
| Gréisst | 14.1 |
| Applikatioun | NBPC |
| Opléisung | 1400×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | 150 |
| CR | 200:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | BOE HYDIS |
| Panel Modell | HT14P12-100 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.1 inch |
| Resolutioun | 1400(RGB)×1050 , SXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 285.6×214.2 mm |
| skizzéieren | 299×228×5.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | |
| Hellegkeet | 150 cd/m² (Typ.) |
| Kontrast Verhältnis | 200:1 (Min.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 25/25 (Max.)(Tr/Td) |
| Vue Wénkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
