| Part Number | HSD156JUW2-A10 |
| Mark | HannStar |
| Gréisst | 15.6 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , 30K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | HannStar |
| Écran Gréisst | 15.6 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 141PPI |
| aktiv Beräich (mm) | 344.16 × 193.59 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 850 (Typ.)(cd/m²) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% |
| mass | TBD |
| Erfrëschungsrate | 60Hz |
| Modell Numm | HSD156JUW2-A10 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 363.7 × 215.7 (H×V×D) |
| Behandlung | Hard coating |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Aarbecht Modus | IPS Pro, Normally Black, Transmissive |
| Äntwert | 15/15 (Max.)(Tr+Td) ms |
| benotzt fir | Outdoor High Brightness Automotive Display |
| touchscreen | Without |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF3-SLB3 | LG Display | 15.6 | 1920×1080 |
| LP156WH3-TLQ1 | LG Display | 15.6 | 1366×768 |
| LTN156AT01-A01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
