| Part Number | HSD070JDW6-A00 |
| Mark | HannStar |
| Gréisst | 7.0 |
| Applikatioun | Automotive Display |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | HannStar |
| diagonal Gréisst | 7.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 133PPI |
| aktiv Beräich | 152.4(H)×91.44(V) mm |
| bezel Beräich | 154.4(H)×93.44(V) mm |
| luminance | 1000 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Gewiicht | 153±10g |
| Frame Taux | 60Hz |
| Modell | HSD070JDW6-A00 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 165(H)×104.07(V) ×8.5(D) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Betribssystemer Modus | IPS Pro, Normally Black, Transmissive |
| Liichtquell | WLED [7S4P] , 30K hours , W/O Driver |
| entworf fir | Automotive Display |
| Touch Panel | Without |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV4-TD02 | LG Display | 7.0 | 800×480 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| TX18D37VM0AQA | KOE | 7.0 | 800×480 |
