| Part Number | HSD070I651-D00-0299 |
| Mark | HannStar |
| Gréisst | 7.0 |
| Applikatioun | Digital Photo Frame |
| Opléisung | 480×234 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | Full |
| Géigeliicht | No B/L |
| Interface | |
| Fabrikant beschwéiert | HannStar |
| Modell Numm | HSD070I651-D00-0299 |
| Écran Gréisst | 7.0 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×234 76PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 154.08 × 86.58 (H×V) |
| Kontur (mm) | 164.9 × 100 × 1.69 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 60/60/40/60 (Typ.)(CR≥10) |
| Äntwert | 5/20 (Typ.)(Tr/Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Glas deck | 0.63+0.63 mm |
| transmissivitéit | 9.0% (Typ.)(with Polarizer) |
| Faarfdéift | Full color |
| mass | 55.3/58.3g (Typ./Max.) |
| benotzt fir | Digital Photo Frame Portable DVD Player |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
