| Part Number | HB140WX1-411 |
| Mark | BOE |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | 9S4P |
| Interface | eDP |
| Panel Mark | BOE |
| Panel Modell | HB140WX1-411 (BOE0600) |
| Panel Gréisst | 14.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1366(RGB)×768, WXGA, 112PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 309.399(W)×173.952(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 320.4(W)×205.1(H) ×3.6(D) mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Vue Wénkel | 45/45/20/40 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 6 o'clock |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 45% NTSC |
| Lampe Typ | 9S4P WLED , 15K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Form Stil | Flat (PCBA Flat, T3.4~4.0mm) |
| Applikatioun | Laptop |
| Signal Interface | eDP (1 Lane) , HBR1 (2.7G/lane) , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
