| Part Number | GV185FHM-N10-DM30 |
| Mark | BOE |
| Gréisst | 18.5 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 11S4P |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | GV185FHM-N10-DM30 |
| Panel Gréisst | 18.5" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×1080, FHD, 119PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 408.96(W)×230.04(H) mm |
| bezel Ouverture | 410.96(W)×232.04(H) mm |
| Kontur Gréisst | 430.4(W)×254.6(H) ×12.5(D) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 70% NTSC |
| Lampe Typ | 11S4P WLED , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 1.80Kgs (Typ.) |
| Applikatioun | Industrial |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
