| Part Number | GV185FHM-N10-3M30 |
| Mark | BOE |
| Gréisst | 18.5 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | BOE |
| Modell | GV185FHM-N10-3M30 |
| diagonal Gréisst | 18.5 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 119PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 408.96(H)×230.04(V) mm |
| kontur dim. | 430.4(H)×254.6(V) ×12.5(D) mm |
| bezel Beräich | 410.96(H)×232.04(V) mm |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Liichtquell | WLED [11S4P] , With LED Driver |
| Gewiicht | 1.80Kgs (Typ.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 5.0V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
