| Part Number | GV101WXB-NZ1-DGP0 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1280×800 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L , With LED Driver |
| Interface | |
| Fabrikant beschwéiert | BOE |
| Modell Numm | GV101WXB-NZ1-DGP0 |
| Écran Gréisst | 10.1 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 1280(RGB)×800 (WXGA) 149PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 216.96 × 135.6 (H×V) |
| Kontur (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Without Polarizer, Hard coating |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 35 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | ADS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| mass | - |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| TT101WSQ-N10 | BOE | 10.1 | 1024×600 |
