| Part Number | G190SF01 V0 |
| Mark | AUO |
| Gréisst | 19.0 |
| Applikatioun | IA |
| Opléisung | 1680×342 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 2000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G190SF01 V0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 19.0 inch(1/3 cut of 22.0") |
| Resolutioun | 1680(RGB)×342 |
| Display Modus | P-MVA, Normally Black, Transmissive |
| aktiv Beräich | 473.76×96.44 mm |
| skizzéieren | 493.7×124.8×18.5 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S5PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | IA |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| G190SVT01.0 | AUO | 19.0 | 1680×342 |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| LM190E08-TLG3 | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTN190W1-L01 | Samsung | 19.0 | 1680×1050 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| M190EN03 V0 | AUO | 19.0 | 1280×1024 |
| AA104SL02-DE1 | Mitsubishi | 10.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| G321EV5B000 | SII | 4.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| LM104VC1T51H | SHARP | 10.4 | 640×480 |
| LQ150X1LW73 | SHARP | 15.0 | 1024×768 |
| LTA121B860F | TOSHIBA | 12.1 | 800×600 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| NL8060BC31-28D | NLT | 12.1 | 800×600 |
