| Part Number | G185XW01 V201 |
| Mark | AUO |
| Gréisst | 18.5 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G185XW01 V201 |
| Panel Gréisst | 18.5" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1366(RGB)×768, WXGA, 84PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 409.8(W)×230.4(H) mm |
| bezel Ouverture | 413.4(W)×234.0(H) mm |
| Kontur Gréisst | 430.4(W)×254.7(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 3.5/1.5 (Typ.)(Tr/Td) |
| weisen Faarwen | 16.7M 70% NTSC |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 1.44Kgs (Max.) |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
