| Part Number | G170ETN03.1 |
| Mark | AUO |
| Gréisst | 17.0 |
| Applikatioun | Industrial |
| Opléisung | 1280×1024 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G170ETN03.1 |
| diagonal Gréisst | 17.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×1024 [SXGA] 96PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 337.92(H)×270.336(V) mm |
| kontur dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| bezel Beräich | 341.7(H)×274.1(V) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 3.8/1.2 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED [9S4P] , 30K hours , W/O Driver |
| Gewiicht | 1.27Kgs (Typ.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 5.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
