| Part Number | G156XW01 V4 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | AUO |
| Panel Gréisst | 15.6" |
| Resolutioun | 1366(RGB)×768, WXGA, 100PPI |
| Affichage Beräich | 344.232(W)×193.536(H) mm |
| Kontur Gréisst | 363.8(W)×215.9(H) mm |
| Hellegkeet | 500 cd/m² (Typ.) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| beschte Vue op | - |
| weisen Faarwen | 16.2M 62% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 860±40g |
| Panel Modell | G156XW01 V4 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 347.54(W)×196.83(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 6/2 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
| G156XW01 V0 | AUO | 15.6 | 1366×768 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| G156XW01 V3 | AUO | 15.6 | 1366×768 |
| LP156WF6-SPH3 | LG Display | 15.6 | 1920×1080 |
| LP156WH1-TLC1 | LG Display | 15.6 | 1366×768 |
| LTN156AT35-W02 | Samsung | 15.6 | 1366×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
