| Part Number | G156XTN02.1 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AUO |
| Panel Modell | G156XTN02.1 (AUO21EC) |
| Panel Gréisst | 15.6" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1366(RGB)×768, WXGA, 100PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 344.232(W)×193.536(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 359.5(W)×223.8(H) ×3.3(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Vue Wénkel | 80/80/55/70 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 6 o'clock |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 45% NTSC |
| Lampe Typ | WLED , 15K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 380g (Max.) |
| Applikatioun | Industrial |
| Signal Interface | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
